Best IPAM Tools, Solutions, Software and Vendors Comparison. To help you find the best IPAM solutions, IT Central Station ranked them based on hundreds of real user reviews, from our esteemed community of enterprise technology professionals. Use our free recommendation engine to learn which IPAM Tools solutions are best for your needs.

NIPAP is a sleek, intuitive and powerful IP address management system built toefficiently handle large amounts of IP addresses.

Having been developed at a fairly large service provider with operationsthroughout Europe, NIPAP is well suited for large organisations with massiveamounts of IP addresses just as well as smaller enterprises with simple needs.The intuitive web interface lowers the barrier of entry considerable forbeginner users while also offering advanced search by regexp and IPv4/IPv6prefix. It features a powerful Google-style search, both a web GUI and a CLItogether with client libraries for Python, Java and Oracle for those that wantto integrate with other systems.

Features in short:

  • Very fast and scalable to hundreds of thousands of prefixes
  • A stylish and intuitive web interface
  • Native support for IPv6 (full feature parity with IPv4)
  • CLI for the hardcore user
  • Native VRF support, allowing overlapping prefixes in different VRFs
  • Support for documenting individual hosts
  • Very powerful search function (featuring regexp)
  • Statistics over used and free addresses
  • Integrated audit log
  • IP address request system for automatically assigning suitable prefixes
  • XML-RPC middleware, allowing easy integration with other applications or writing
  • Flexible authentication using SQLite and/or LDAP

Check out the webpage for information, screenshots and more:http://SpriteLink.github.com/NIPAP

Getting started

If you are running Ubuntu / Debian, add the following repo:

And install nipapd for the backend, nipap-cli for the cli and/or nipap-www forthe web pages.

Also see 'Getting it' at http://SpriteLink.github.io/NIPAP.

Contributing

Contributions to NIPAP are more than welcome. Please take a moment to reviewour contribution guidelines to make the contribution processeasy and effective for everyone involved!

Community

Keep track of development and community news:

  • Follow NIPAP news on Google+
  • Chat with other users and the core team on IRC. irc.freenode.net / #NIPAP

Versioning

While we have messed up some times, we try to adhere tothe Semantic Versioning guidelines.

Note how NIPAP hasn't reached 1.0 yet which means there might still besubstantial changes to APIs and similar. While we try to keep it to a minimum,there will inevitable be changes to progress development.

Copyright and License

Code released under the MIT license. Documentation released underCreative Commons.

-->

Applies To: Windows Server 2012 R2, Windows Server 2012

This topic provides a summary of the IP Address Management (IPAM) Server feature in Windows Server® 2012 and Windows Server 2012 R2. For detailed information, see the following topics:

Topic

Guidance

This topic provides information about additions and changes in IPAM in different Windows Server operating system versions.

Step-by-step procedures are provided for using IPAM in a test environment.

Architectural and planning information for IPAM is provided.

Provides detailed, click-by-click deployment instructions to deploy IPAM in a production environment.

Provides operational, troubleshooting, and best practices guidance for IPAM.

Two virtual labs are available for Windows Server 2012, including Managing Your Network Infrastructure with IP Address Management, which demonstrates IPAM only, and Building a Resilient Network Infrastructure, a virtual lab that combines IPAM with DNSSEC and DHCP failover in Windows Server 2012. Note: Virtual labs might require some time to start.

Provides a list and examples of available Windows PowerShell cmdlets for IPAM server.

Feature description

IP Address Management (IPAM) in Windows Server® 2012 and Windows Server® 2012 R2 is an integrated suite of tools to enable end-to-end planning, deploying, managing and monitoring of your IP address infrastructure, with a rich user experience. IPAM automatically discovers IP address infrastructure servers on your network and enables you to manage them from a central interface.

IPAM includes components for:

  1. Virtual Address Space Management*

  2. Role-based access control**

* Virtual IP address space management is enabled through integration of IPAM with system center virtual machine manager and is available in Windows Server 2012 R2 and later operating systems. This feature is not available with IPAM in Windows Server 2012.

** Role-based access control is available in Windows Server 2012 using local user groups on the IPAM server. This feature was significantly enhanced in Windows Server 2012 R2 to include detailed built-in and custom role-based access groups.

Also see the following sections in this topic:

  • IPAM deployment options: Provides a summary of IPAM design choice. For detailed information, see IPAM Architecture.

  • IPAM specifications: Provide a summary of IPAM deployment requirements and capabilities.

For information about getting started with IPAM, see Using the IPAM Client Console.

Address Space Management

IPAM’s address space management (ASM) feature enables you to gain visibility into all aspects of your IP address infrastructure from a single console. With IPAM, you can create a highly customized, multi-level hierarchy of address space on your network and use it to manage IPv6 addresses and IPv4 public and private addresses. The ASM feature includes a robust reporting capability that enables detailed tracking of IP address utilization trends with customized thresholds and alerts.

Key features of ASM include the following.

  • Integrated management of dynamic and static IP address space

  • Detection and management of conflicts, overlaps, and duplicates in address space across systems

  • Highly customizable inventory view of IP address space

  • Centralized monitoring and reporting of address utilization statistics and trends

  • Support for IPv4 and stateless IPv6 address utilization monitoring

  • Automated discovery of IP address ranges from DHCP scopes

  • Export and import of IP addresses and IP address ranges with Windows PowerShell support

  • IP address usage alerts and notifications with custom thresholds

  • Detection and assignment of available IP addresses

The following example shows how IPAM’s ASM feature enables you to monitor IP address utilization. In this example, 7 days of utilization data is displayed for the 10.72.144.0/22 IP address range.

Best ipam software

For more information, see Managing IP Address Space.

Virtual Address Space Management

IPAM in Windows Server 2012 R2 includes the ability to manage virtual IP address space that is configured using system center virtual machine manager (VMM).

IPAM’s virtual address space management (VASM) feature enables the same functions and capabilities for your virtual IP address infrastructure as the ASM feature does for physical IP address space.

For more information, see Managing Virtual IP Address Space.

Multi-Server Management and Monitoring

IPAM’s multi-server management (MSM) feature enables you to automatically discover DHCP and DNS servers on the network, monitor service availability, and centrally manage their configuration. Using the Group Policy provisioning mode, IPAM provides quick and painless provisioning of agentless IPAM access settings on managed servers. A manual provisioning mode is also available.

Key features of MSM include the following.

What Does Ipam Do

  • Discovery of Microsoft DHCP and DNS servers automatically across an Active Directory forest

  • Manual addition or removal of managed servers

  • End-to end configuration and management of DHCP servers and scopes

  • Support for advanced constructs to enable add, delete, overwrite, or find and replace operations on multiple DHCP scopes and servers

  • Simultaneous update of common settings across multiple DHCP scopes or DHCP servers

  • Availability monitoring for DHCP and DNS services and DNS zones

  • Management of Microsoft DHCP and DNS servers running Windows 2008 or later operating systems

  • Addition of custom information to servers enabling visualization using logical groups based on business logic

  • Monitoring of DHCP scope utilization

  • Automatic and on-demand retrieval of server data from managed DHCP and DNS servers

  • DNS zone status monitoring based on DNS zone events

  • Classify discovered servers and roles as managed or unmanaged

The following example shows how IPAM’s MSM feature enables you to monitor IP DHCP scopes on the network. In this example, detailed data is displayed for the scope US_SEA_zzz3.

For more information, see Multi-server Management.

Network Audit

IPAM’s audit feature provides a centralized repository for all configuration changes performed on DHCP servers and the IPAM server, and for IP addresses issued on the network. IPAM audit tools enable you to view potential configuration problems on DHCP servers by actively tracking and reporting all administrative actions. Detailed IP address tracking data is also provided, including client IP addresses, client ID, host name, and user name. Advanced search capabilities enable you to selectively search for events and obtain results that associate user logons to specific devices and times.

Key features of network audit include the following.

  • Query the event catalog for DHCP configuration changes across multiple servers from a single console

  • Track users, devices, and IP addresses for specified intervals with advanced queries using DHCP lease logs and logon events from domain controllers and network policy servers

  • Track and report changes made to the IPAM server

  • Export audit findings and create reports

  • Quickly resolve configuration problems and track service level agreements

The following example shows how IPAM’s network audit feature enables you to track IP addresses on the network. In this example, details are displayed for a lease event in the contoso.com domain.

For more information, see IP Address Tracking and Operational Event Tracking.

Role-based access control

IPAM’s role-based access control feature enables you to customize the types of operations and access permissions for users and groups of users on specific objects in IPAM. Role based access control in Windows Server 2012 is less fine-grained than in Windows Server 2012 R2. See the following comparison.

Group

Windows Server 2012

Windows Server 2012 R2

Local IPAM security groups

IPAM Users

IPAM ASM Administrators

IPAM MSM Administrators

IPAM IP Audit Administrators

IPAM Administrators

IPAM Users

IPAM ASM Administrators

IPAM MSM Administrators

IPAM IP Audit Administrators

IPAM Administrators

Built-in IPAM role-based access groups

N/A

DNS Record Administrator

IP Address Record Administrator

IPAM Administrator

IPAM ASM Administrator

IPAM DHCP Administrator

IPAM DHCP Reservations Administrator

IPAM DHCP Scope Administrator

IPAM MSM Administrator

Custom IPAM role-based-access groups

N/A

Unlimited

IPAM deployment options

An IPAM server is a domain member computer.

Free

Important

You cannot install the IPAM feature on an Active Directory domain controller.

There are three general methods to deploy IPAM servers:

  1. Distributed: An IPAM server deployed at every site in an enterprise.

  2. Centralized: One IPAM server in an enterprise.

  3. Hybrid: A central IPAM server deployed with dedicated IPAM servers at each site.

The following example displays the distributed IPAM deployment method, with one IPAM server located at the corporate headquarters and also at each branch office. There is no communication or database sharing between different IPAM servers in the enterprise. If multiple IPAM servers are deployed, you can customize the scope of discovery for each IPAM server, or filter the list of managed servers. A single IPAM server might manage a specific domain or location, perhaps with a second IPAM server configured as a backup.

IPAM will periodically attempt to locate domain controllers, DNS, and DHCP servers on the network that are within the scope of discovery that you specify. You must choose whether these servers are managed by IPAM or unmanaged. In this way, you can select different groups of servers that are managed or not managed by IPAM.

To be managed by IPAM, security settings and firewall ports on a server must be configured to allow the IPAM server access so that it can perform required monitoring and configuration functions. You can configure these settings manually, or automatically using Group Policy Objects (GPOs). If you choose the automatic method, settings are applied when a server is marked as managed and settings are removed when it is marked as unmanaged.

The IPAM server will communicate with managed servers using an RPC or WMI interface. IPAM monitors domain controllers and NPS servers for IP address tracking purposes. In addition to monitoring functions, several DHCP server and scope properties can be configured from the IPAM console. Zone status monitoring and a limited set of configuration functions are also available for DNS servers. See the following figure.

For more information, see IPAM Architecture.

IPAM specifications

The scope of IPAM server discovery is limited to a single Active Directory forest. The forest itself may be comprised of a mix of trusted and untrusted domains. IPAM requires membership in an Active Directory domain, and relies on a functional network infrastructure environment to integrate with other server installations across the AD forest.

IPAM has the following specifications:

  1. IPAM supports only Microsoft domain controllers, DHCP, DNS, and NPS servers running Windows Server® 2008 and above.

  2. IPAM supports only domain joined DHCP, DNS and NPS servers in a single AD forest.

  3. In its recommended configuration, IPAM is installed on a standalone server. You cannot install IPAM on a domain controller. If IPAM is installed on the same server with the DHCP Server role service, automatic discovery of DHCP servers on the network will be disabled.

  4. IPAM does not support management and configuration of non-Microsoft network elements. However, you can use Windows PowerShell to import and manage IP address data from non-Microsoft devices.

  5. IPAM in Windows Server 2012 does not support external databases. Only a Windows Internal Database is supported.

  6. A single IPAM server has been tested to support up to 150 DHCP servers and 500 DNS servers.

  7. A single IPAM server has been tested to support up to 40,000 DHCP scopes and 350 DNS zones.

  8. IPAM has been tested to store 3 years of forensics data (IP address leases, host MAC addresses, user login/logoff information) for 100,000 users in a Windows Internal Database. Data is not purged automatically. An administrator must purge data manually as needed.

  9. IP address utilization trends are provided only for IPv4.

  10. IP address reclaiming support is provided for IPv4 and IPv6.

  11. IPAM does not check for IP address consistency with routers and switches.

  12. IPAM does not support auditing of IPv6 stateless address auto configuration on an unmanaged machine to track the user.

  13. IPAM supports integration with System Center Virtual Machine Manager (VMM) using a Windows PowerShell script that is packaged and shipped with System Center VMM. This integration enables IPAM to display detailed utilization and inventory data for IP addresses and IP address ranges used in System Center VMM.

Gestioip

Practical applications

Windows

Free Ipam Software Windows

Monitoring and managing the IP address infrastructure on a corporate network is a critical part of network administration, and has become increasingly challenging as networks grow more dynamic and complex. Many IT administrators still track IP address allocation and utilization manually, using spreadsheets or custom database applications. This can be very time consuming and resource intensive, and is inherently prone to user error. IPAM in Windows Server 2012 provides a platform to manage the following IP administration needs.

Best Free Ipam Software

  1. Planning: IPAM replaces manual tools and scripts that can introduce added time, inconsistency and expense into the planning process when business expansions and alterations occur, or new technology and scenario adoptions are required.

  2. Managing: IPAM provides a single management platform for IP address administration on the network. IPAM also allows for optimized utilization and capacity planning for DHCP and DNS services in distributed environment.

  3. Tracking: IPAM enables tracking and forecasting of IP address utilization. As the demand for public IPv4 address space continues to grow in an environment with limited supply, this can be of critical importance to an organization.

  4. Auditing: IPAM assists with compliance requirements such as HIPAA and Sarbanes-Oxley, and provides reporting for forensics and change management.

Free Ip Address Management Tool

New and changed functionality

See What's New in IPAM.

Server Manager information

The installation of the IPAM Server feature can be performed through the Server Manager. The following features and tools are installed automatically when you install IPAM Server:

Feature or Tool

Description

Remote Server Administration Tools

DHCP and DNS Server Tools and IP Address Management (IPAM) Client provides for remotely managing DHCP, DNS and IPAM servers.

Windows Internal Database

Windows Internal Database is a relational data store that can be used only by Windows roles and features.

Windows Process Activation Service

Windows Process Activation Service generalizes the IIS process model, removing the dependency on HTTP.

Group Policy Management

Group Policy Management is a scriptable Microsoft Management Console (MMC), providing a single administrative tool for managing Group Policy.

.NET Framework 4.5 Features

.NET Framework 4.5 provides a programming model for building and running applications designed for several different platforms.
